Solar Power System 48V LiFePO4 Lithium Wall-Mounted Battery 5kw 10kwh Home Use Energy Storage System Power Wall Mounted

Place of Origin : china

MOQ : negotiated

Price : negotiated

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram, MoneyGram

Delivery Time : negotiated

Battery Type : LiFePO4

Output Power Range : 5~20 kWh

Cycle life : 6000 Times

Warranty : 5 Years

Nominal Voltage : 51.2V

Contact Now

Solar Power System 48V LiFePO4 Lithium Wall-Mounted Battery 5kw 10kwh Home Use Energy Storage System Power Wall Mounted

Key Features

SMART BMS: Built in 165 smart BMS, protect thebattery from running normally, prevent the battery from overcharging, overdischarging, shortcircuit, overcurrent, easier to connectto the inverter, and simple to install.

LASER WELDING: Use a professional spot welder forbattery welding to ensure that there is no problem with the internalconnection of the battery, reduceinternal resistance, avoid poorcontact during battery operation, and greatly improve battery life.

Electrical Characteristics	Nominal Voltage	51.2
	Nominal Capacity	100Ah/200Ah
	Energy	5Kwh ,10Kwh
	Internal Resistance(AC)	≤20mΩ
	Cycle Life	>5000 cycles @ 1C 80% DOD
	Months Self Discharge	<3%
	Efficiency of Charge	100% @0.5C
	Efficiency of Discharge	96~99% @1C
Standard Charge	Charge Voltage	58.4±0.2V
	Charge Current	1C max, default 0.5C
	Max. Charge Current	1C max, default 0.5C
	Charge Cut-off Voltage	62.4±0.2V
Standard Discharge	Continuous Current	1C max, default 0.5C
Standard Discharge	Discharge Cut-off Voltage	43.2V
Environmental	Charge Temperature	0ºC to 55ºC (32F to 131F) @60±25% Relative Humidity
	Discharge Temperature	-20ºC to 60ºC (-4F to 140F) @60±25% Relative Humidity
		Humidity
	Storage Temperature	-20ºC to 60ºC (-4F to 140F) @60±25% Relative Humidity
	IP Class	IP30

Solar Power System 48V LiFePO4 Lithium Wall-Mounted Battery 5kw 10kwh Home Use Energy Storage System Power Wall Mounted

FAQ

Q:Do you have MOQ?

Re: No limited. sample is OK. More quantity has better price, we will give you more discount and check the bestprice for you.

Q: What's the delivery time?
Re: Generally within 7-15 days, we well arrange it for you as soon as possible.

Q: Can i make up the battery pack by myself?
Re: Yes, you can DIY by yourself.If you worry about it can't work with BMS and inverter, we can provide you with them, and makesure they can be match

Q:Which shipping method you usually take?
Re: Train/Sea DDP, Express, We can also ship with your own shipping agent.
