Home Off Grid Energy Storage Lithium Battery System 10kwh 15kwh 20kwh

Place of Origin : china

MOQ : negotiated

Price : negotiated

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Delivery Time : negotiated

Output Power Range : 10~20 kWh

Weight : 160kg

Capacity : 5kwh-20kwh

Battery Type : Lithium Ion

Inverter Type : Off-grid Power Inverter

Dimension (L*W*H) : 180*20*50cm

Contact Now

All In One Energy Storage System

All-in-one energy storage system, built-in hybrid optical storage inverter and lithium battery system.

Achieve the best performance with the highest efficiency, and let families use clean energy all day long.

Home Off Grid Energy Storage Lithium Battery System 10kwh 15kwh 20kwh

Home Off Grid Energy Storage Lithium Battery System 10kwh 15kwh 20kwh

Technical parameter	Y00500100LG	Y00500150LG	Y00500200LG
Mains power input
Rated input voltage(V)	220/230
Input voltage range (V)	90-280
Frequency range(Hz)	50/60
Maximum mains charging current(A)	60
Battery (built-in)
Battery type	Lithium battery
Rated voltage(V)	51.2
Input voltage range (V)	44.8 -57.6
Stored electric energy (KWh)	10.24/15.36/20.48
PV input
Maximum input power(W)	5000
Input voltage range (V)	120-500
Recommended PV string voltage(V)	120-450
Number of MPPT routes	1
Maximum photovoltaic charging current(A)	80
AC output
Rated output power (W)	5000
Peak output power (W)	10000
Rated output voltage (V)	220/230
Output frequency range (Hz)	50/60
No load loss	Non energy saving mode: ≤ 50W; Energy saving mode: ≤ 25W (to be set)
Output voltage distortion rate THD	±5%
Peak efficiency	＞90%
Overload protection	Short circuit protection, over-voltage and undervoltage protection, overload protection, reverse irrigation protection
Other parameters
Operating temperature range(℃)	-10-45℃
Humidity range	5%-85%
Protection grade	IP20
Operating altitude(m)	＜2000
Noise(dB)	＜60
Cooling mode	forced air cooling
Isolation mode	Natural air cooling
Display mode	LED/APP
Communication mode	RS485/CAN/WIFI
Reference dimension(WDH)mm	710×450×600/800/1000
Reference weight(kg)	133/186/239

All-in-one energy storage system advantages

Convenient: Full field thermal simulation design, optimal battery layout Quiet: Less than 25 decibels, extremely quiet, zero disturbance to life Flexible: IP65 grade, 5 and 10 kWh optional Free: Switchable modes of self use, power backup, peak shaving and valley filling Exquisite: No need to add additional modules and photovoltaic inverter Intelligence: Support VPP and AIOT interfaces

Multiple Application Scenarios

FAQ

Q:Can I have a sample order ?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

Q: How do you ship the goods and how long does it take to arrive?
A: by sea, by air and express for option. Sample orders normally use door to door express DHL, UPS, FedEx or TNT or by air to the local airport. Bulk and container orders by sea.

Q: How to proceed an order online ?
A: Send us your inquiry online first, we’ll confirm exactly price including shipping cost for you. After your confirmation of
total cost, online insurance trading order will be made for you. You can pay through Visa, T/T ,WesternUnion online directly.

Q: Is it OK to print my logo ?
A: With MOQ requirements of different products, OEM service is acceptable. Normally 200pcs is acceptable to print customized logo.

Q: How to solve the technical problems?
A: 24 hours after-service consultancy just for you and to make your problem to be solved easily.
